Biomek® FXP laboratory automation workstations can be widely used in sequencing sample preprocessing, drug screening, nucleic acid extraction, chromatographic sample preprocessing, protein purification, ELISA reaction, PCR system construction, Affy system preprocessing and blood station system high-throughput sample analysis. The lab automation workstation's unique sample processor ensures a high degree of automation and standardization of sample processing -- with a micro-reaction system, reducing sample processing costs; Its automatic operation process reduces human error, and the standardized experiment procedure and accurate sample adding process can improve the repeatability of the experiment.

Product characteristics

Biomek® FXP laboratory automation workstation features:

Multi-channel single mechanical arm or double mechanical arm with multi-channel sampler and flexible 8-channel sampler can be combined flexibly

The mechanical arm is equipped with a 96 or 384-channel sampler to maximize the speed of the experiment process; Flexible 8-channel sampler 8 channels can be independently controlled for maximum flexibility

The sampling range is wide and the sampling accuracy is high

The moving plate manipulator can grab the consumables on the table, and realize the operation of transporting and stacking consumables

Infrared light screen is sensitive, if any object into the test area, the machine can be immediately suspended, real-time protection of the experimenter and the program, such as interference elimination, click OK after the program can continue to run

Optical positioning system, accurate positioning, convenient, can also operate 1,536 plates

Biomek FXP is an open system, which can be expanded at any time by adding new functional modules on the basis of liquid treatment

With strong integration function, it can be integrated with a number of third-party equipment to realize the full automation of the experiment, such as PCR instrument, centrifuge, enzyme label instrument, fluorescence quantitative PCR instrument, incubator, etc

Advanced timing optimization software -- Sami EX, seamlessly connected third-party devices and Biomek automated workstations, real-time data tracking, powerful timing optimization capabilities, simple and efficient use of resources

Simple and flexible Biomek software, intuitive interface, click and drag programming, accurate pipetting operation in the hole, and complete data tracking

Equipped with barcode reader can automatically complete the input and tracking of sample information

Comply with the requirements of 21CFR, Part 11

A unified software platform, the Biomek series pipetting platforms are all controlled by the same interface, greatly reducing the operator's learning time. Biomek software allows a variety of experimental methods to be converted between platforms, avoiding reprogramming

The product application

Biomek® FXP Laboratory Automation Workstation Applications:

The first choice of drug screening: whether primary screening or secondary screening, or intermediate replication and rearrangement tasks; High-throughput automated screening of lead compounds and potential compounds libraries can be performed to efficiently complete absorption, metabolism and toxicity tests

Providing high-throughput genomic solutions:

O Complete nucleic acid extraction of high throughput samples with various nucleic acid extraction kits from Beckmann Kurt or third-party kits

O High throughput sequencing sample preprocessing or PCR product purification with Beckman Coulter's AMPure XP product purification kit

O Complete screening of a specific range of nucleic acid fragments with the Beckman Coulter SprisElect nucleic acid screening kit

High throughput chromatographic sample preprocessing, including metabolome, proteome and small molecule analysis

Complete MALDI sample plate sampling with high throughput, and realize protein quantification, nucleic acid quantification and microbial identification

In the aspect of proteome, cell and microorganism analysis, it can complete a series of operations such as medium packing, microbial inoculation, cell culture, protein purification, enzyme activity screening and so on. At the same time, it can also be integrated with third party equipment to achieve full automation

Product parameters

Biomek® FXP laboratory automation workstation technical parameters:

The workstation

Weight 125kg including base, single arm and top cover.

Height 109.2 cm.

The height of the top cover is 139.7cm.

Width is 152.4 cm.

The width of the top cover is 162.5cm.

Depth of 81.3 cm.

Power required 50/60Hz, 100-240VAC.

It can accommodate 24 standard plates.

Types of ALP: oscillators, automatic lifting magnetic racks, cleaning devices, heating and cooling devices.

Safety protection device: infrared light screen.

Commonly used pipetting consumable options

96-channel disposable suction heads, AP20, P50 and AP250 suction heads are available, as well as filter, sterile and wide mouth suction heads

384 channel disposable suction head, AP30UL suction head, can provide sterilization suction head

Flexible 8-channel Span8 disposable suction head, Span20, P50, Span250 and Span1000 suction head for choice, but also can provide filter suction head, sterile suction head and wide mouth suction head

Flexible 8-channel Span8 fixed needle applicator, available in FIX60 and FIX100

Flexible 8-channel Span8 catheter sealing puncture needle

Flexible 8-channel SPAN8 liquid level detection heads are available with SPAN20, P50, SPAN250 and SPAN1000 heads

Gripper manipulator

Automatically complete the transport of consumables, complete nucleic acid purification and other processes, as well as the transfer of microplates to the enzyme plate instrument.

Minimum surface area

92cm wide x77cm deep, bearing 181.4kg.
